BEA Sensor Eagle 6+ DRO

TECHNOLOGY	Microwave doppler radar
TRANSMITTER FREQUENCY	24.150 GHz
CABLE LENGHT	2.5m
TRANSMITTER POWER DENSITY	< 5 mW / cm²
TILT ANGLES	0 – 90° vertical; -30 – 30° lateral
DETECTION MODE	Motion
MIN. DETECTION SPEED	5cm/s (measured in sensor axis)
SUPPLY VOLTAGE	12 - 24V AC +/- 10%; 12 - 24V DC +30% / - 10%
MAINS FREQUENCY	50 - 60 Hz
max POWER CONSUMPTION	< 2 W
OUTPUT	relay (free of potential change-over contact) Max. contact voltage: 42 V AC/DC Max. current: 1 A (resistive) Max. switching power: 30 W (DC)/60 VA (AC)
MATERIAL	ABS
TEMPERATURE RANGE	-20°C to +55°C
DEGREE OF PROTECTION	IP54
MOUNTING HEIGHT	1.8m to 4m
TRANSMITTER RADIATED POWER	< 20 dBm EIRP
DIMENSIONS	120mm (L) × 80mm (H) × 50mm (W)
